- Realisation "double walled". with thermic insulation.
- Water softener continuously, incorporated
- Charging height dishes diam. 450 mm.
- From 60 till 24 baskets/hour, 3 cycles 60'' - 120"-80" or continuous.
- Device opening and closing cover on connecting rods
- Vertical wash pump (dual flow), self-draining and self-cleaning.
- Rotating wash and rinse arms.
- Self cleaning sprinklers.
- Adjustable stainless steel feet (160-220 mm).
- Front control panel.
- Automatic filling of the tank.
- Check valve.
- Hot water rinse, stainless steel boiler (12 Lit., 8 kW).
- Micro switch, when the door opens.
- Safety thermostat.
- Manufactured in stainless steel AISI 304.
- Standard : 2 baskets, 1 goblet.
- Fully "pressed" tank, double wall (2,5 kW).
- "Integrated" tank's filter in stainless steel.
- "Peristaltic" dispenser of rinse product supplied as standard.
- On request: "peristaltic" dosing kit of liquid detergent and drain pump kit.
- "Patented" pump filter allowing to conserve the washing water longer and at good temperature.
- CSD digital control panel (soft touch).
- EED energy saving.
- DRD accelerated preheating phase.
- DID automatic diagnostic in case of problems.
- ADD display of boiler and tank temperature (HACCP conform)
- RGD Constant rinsing T° of 85°C, stable pressure during all the rinsing cycle.
- BTD "Break Tank" anti-pollution device, AB type.
- NB: machines guaranteed for "osmosis" water supply.
ADVANTAGE - BREAK TANK :
The "break tank" is an AB type "anti-pollution" device (UK standards) 1) It prevents the tank water (with detergents) to flow back into the distribution system 2) Its pump guarantees a constant pressure during the whole rinsing, the drying and hygiene are guaranteed by a T° of 85°C... until the last drop of water!
ADVANTAGE - SAVE THE PLANET :
Latest generation machines, avant-garde technologies respectful of the planet, low energy, water and detergent consumption, thanks to a more contained tank and a "patented" filter that keeps the wash water at the right temperature, as well as a high efficiency wash pump (double flow).
ADVANTAGE - Continuous Water Softener :
The softener continuously, constantly keeps softened water, regardless of the number of wash cycles, for perfect results and offers the advantage of not having to stop the dishwasher to allow the regeneration of resins. During the micro-interruptions wash cycle used to regenerate the resins, while continuing to wash!
Technical Specification
- mm (W x D x H) : 710 x 800 x 1530/2010 - kW (elec) : 8.7 - Voltage : 400-230/3N 50Hz
- Category: Diamond
- Range: Washing
- Subfamily: DOUBLE SKIN / SOFTENER
- Line: ACTIVE WASH
- Length: 710 mm
- Width: 800 mm
- Height: 1530/2010 mm
- Electric Power: 8.7 kW
- Voltage: 400-230/3N 50Hz
- Weight: 130 kg
