Refrigerated group " Overlapping " T° -5°+5°

Description

  • Cooling capacity delivered: 2003 (W/f) for chamber volume 23.9 m³ / 23900 Lit (internal T° 0°C & external T° +32°C)
  • Refrigerant expansion by thermostatic valve



  • "Overlapping" refrigeration units.
  • Unit certified in climatic class 5 (40°C Temperature - 40% Humidity).
  • All units are supplied as standard with a high pressure switch and KVL valve.
  • Automatic hot gas defrost with self-evaporation and overflow.
  • The evaporator drain pipe is equipped with a resistor to prevent ice formation.
  • Refrigerant gas R290.
  • Supplied with cables and micro-switch for door and light (Porthole lights supplied as standard).
  • Microprocessor control with touch-sensitive keys.

INFO:
Warning: by default, the ideal operating ambient temperature must not be below 5°C.
If placed outdoors, the unit must be protected from weather conditions.

PLUS:

  • Low-profile 420mm long units. Can be placed on any of our chambers (minimum 600mm panel).
  • All units are supplied as standard with a high-pressure switch. All units are fitted with a thermostatic valve.

Technical Specification

  • mm (W x D x H) : 670 x 390/975 x 828 - T° : -5°+5° - kW (elec) : 1.2
  • Category: Diamond
  • Range: Refrigeration
  • Subrange: Cold & freezing rooms
  • Family: Groupes to chevauchement
  • Subfamily: T°-5° +5°
  • Line: MONOBLOCK
  • Length: 670 mm
  • Width: 390/975 mm
  • Height: 828 mm
  • Electric Power: 1.2 kW
  • Weight: 100 kg
  • Restock Info: 35
  • Supplier Delivery Delay: 42
  • Availability: 0

Read more

Product form

Refrigerated group " Overlapping " T° -5°+5°

5 in stock Fast delivery

Cooling capacity delivered: 2003 (W/f) for chamber volume 23.9 m³ / 23900 Lit (internal T° 0°C & external T° +32°C)... Read more

€3.647,00 €3.256,00
