- High version, easier loading/unloading of baskets.
- "Double-walled" construction.
- With AB (Break Tank) anti-pollution device, including rinsing pump (atmospheric boiler).
- Load height 405mm.
- Plate height 380mm.
- 3 stages: washing, discharge, rinse.
- Drain pump as standard.
- Rinsing pump as standard (atmospheric boiler).
- Double-walled version completely in stainless steel AISI 304. - From 60 to 24 baskets/hour, 60'' - 120'' - 150" or continuous cycles - Rotating wash and rinsing arms (upper and lower), lower arm in stainless steel - Self-cleaning stainless steel nozzles. -Tank (23L, 2,1kW) with rounded edges and deep-drawn base. Deep-drawn basket guides, no rough edges and no scale build-up. - "Integral" tank filter in stainless steel "cast" -"Patented" filter pump keeps wash water cleaner and at the right temperature. - "Stamped" double walled door, removable door seal, stamped handle. - Removable control panel for easy servicing.
- Automatic discharge function of the water tank, integrated into the control panel (no need to remove the plug manually). Automatic filling of the tank. - Non-return valve - Hot water rinse (2,5L water consumption per cycle), stainless steel boiler (with pressure, 7L, 6/8 kW) - Tank and boiler temperature can be regulated - High-efficiency, energy-saving dual-flow wash pump, with "Soft Start" device - Microswitch, when the door opens. - Safety thermostat. - Supplied with: 2 baskets, 1 basket for plates 500x600, 1 generic basket 500x500, 1 cup.
- NB: inclined structure, for desks (on request).
- Peristaltic dispenser for rinsing product and peristaltic dispenser for liquid detergent supplied as standard.
- CSD digital control panel (soft touch).
- EED energy saver.
- TCD control thermostat for guaranteed rinsing at 80°C.
- DRD accelerated pre-heating phase.
- DID self-diagnosis in the event of a fault.
- ADD tank and boiler temperature display (HACCP standard).
- DDD partial tank emptying, evacuation through the bottom of the tank.
- CID ‘soft contact’ automatic closing door (partial opening to evacuate steam).
- RGD rinsing at constant temperature, stable pressure.
- BTD "Break Tank", anti-pollution device, AB type.
- CAD self-cleaning cycle (100% automatic).
-
NB: machines guaranteed for use with ‘osmosis’ treated water supply.
ADVANTAGE - BREAK TANK : The "break tank" is an anti-pollution device, AB type (UK standards). 1) It prevents that the tank water (with detergent) from flowing back to the distribution system. 2) Throughout the rinsing process, its pump guarantees a constant pressure, while drying and hygiene are ensured by a T° of 85°C...until the last drop of water!
ADVANTAGE - SAVE THE PLANET : Latest-generation machines, cutting-edge technologies, energy-saving, low consumption of water and detergent, thanks to the tank with a larger capacity and its "patented" filter to keep the washing water at the right temperature , as well as a high-efficiency wash pump (double flow).
Technical Specification
- mm (W x D x H) : 600 x 695 x 1280 - kW (elec) : 8.7 - Voltage : 400-230/3N 50Hz
- Category: Diamond
- Range: Washing
- Subfamily: CROSSOVER / DOUBLE SKIN
- Line: BEST WASH
- Length: 600 mm
- Width: 695 mm
- Height: 1280 mm
- Electric Power: 8.7 kW
- Voltage: 400-230/3N 50Hz
- Weight: 85 kg
