- From 24 to 40 baskets/hour, 2 cycles: 90‘’-150‘’.
- Hood opening and closing device on connecting rods.
- Rotating upper and lower wash and rinse arms.
- Self-cleaning nozzles.
- Adjustable stainless steel feet (160-220 mm).
- Front control panel.
- Automatic tank filling.
- Non-return valve.
- Hot water rinse (water consumption per cycle 2,6L), stainless steel pressure boiler (6L, 6 kW).
- Microswitch when cover is opened.
- Safety thermostat.
- Made of AISI 304 stainless steel.
- Supplied with: 2 baskets, 1 beaker.
- Fully ‘deep-drawn’ tank (15L, 2,1kW).
- Composite integral tank filter.
- Peristaltic rinse aid dispenser supplied as standard.
- Peristaltic liquid detergent dispenser and drain pump kit available on request.
- Patented filter pump keeps wash water at the right temperature for longer.
- ‘TCD’ rinsing system ensures rinsing at 85°C at all times.
- High-efficiency dual-flow wash pump for significant energy savings.
- Self-cleaning cycle (semi-automatic).
- NB: machines guaranteed for osmosis water supply.
ADVANTAGE - SAVE THE PLANET :
Latest-generation machines, cutting-edge technologies, energy-saving, low consumption of water and detergent, thanks to the tank with a larger capacity and its "patented" filter to keep the washing water at the right temperature , as well as a high-efficiency wash pump (double flow).
Technical Specification
- mm (W x D x H) : 710 x 800 x 1530/2010 - kW (elec) : 6.5 - Voltage : 400-230/3N 50Hz
- Category: Diamond
- Range: Washing
- Subfamily: Standard
- Line: FAST WASH
- Length: 710 mm
- Width: 800 mm
- Height: 1530/2010 mm
- Electric Power: 6.5 kW
- Voltage: 400-230/3N 50Hz
- Weight: 110 kg
